FS S1150-8T2F - Switch to Factory Reset; Recovery the Password of the Switch; Restart the switch

POE+ SERIES SWITCHES RESET AND RECOVERY SYSTEM CONFIGURATION GUIDE
www.fs.com
3
Switch#delete startup-config
this file will be erased, are you sure? (y/n)y
Switch#reboot
*Then prepare tftp
* Then start upgrading the system: run copy tftp flash
Monitor#copy tftp flash //From ftp to flash
Source file name[ ]? FS-S1400-24T4F-2.2.0C.bin //Firmware file name
Remote-server ip address[ ]? 192.168.1.2 //TFTP Server IP address
Destination file name[FS-S1400-24T4F-2.2.0C.bin]? //Switch.bin
When prompted: TFTP: successfulfully sent...
After the success # reboot just fine
3.5 Switch to Factory Reset
If the file name is not entered, the startup-config files will be deleted by default
3.6 Recovery the Password of the Switch
3.6.1 Restart the switch
#After completing the above steps, power off and restart the switch. During the restart process, continuously press “CTRL + P” to enter the
switch system monitoring mode（monitor #） and view the file of the switch.
System Bootstrap, Version 0.4.5, Serial No:CG1908020295N0026
Copyright (c) 2018 by FS.COM All Rights Reserved
FS S5900-24S4T2Q
Current time: 1970-1-1 0:00:00
SDRAM Fast Test...............................PASS!
Flash Fast Test...............................PASS!
RTC Test......................................PASS!
Welcome to S5900-24S4T2Q Ethernet Switch
monitor#dir
Listing Directory /:
Switch.bin <FILE> 11374495 Nov 12 15:33:16 2019
web.wrp <FILE> 30580 Nov 12 16:32:30 2019
startup-config <FILE> 1566 Jan 01 00:02:26 1970
free space is 17872896 bytes
PS. You can view the configuration file under the switch as startup-config through dir.
