FS S2805S Series - Grounding the Switch

1. Connect one end of the grounding cable to a proper earth ground, such as the rack in which the
switch is mounted.
2. Fix the grounding lug to the grounding point on the back panel of the switch with the washers and
screws.
CAUTION: The earth connection cannot be removed unless all supply connections have
been disconnected.
EN
Grounding the Switch
7
100-240V AC50/60Hz
