Step 3: When the Network Properties dialog box is displayed as shown in following figure. Set
Bits per second to 115200, Data bits to 8, Parity to None, Stop bits to 1, and Flow
control to None. (In other Windows operating systems, bits per second may be described
as baud rate and data stream control may be described as traffic control.)
Step 4: Click OK after setting the serial port parameters and input the user name/password:
admin/admin, then enter the HyperTerminal window.
Step 5: Click Properties in the HyperTerminal window to enter the Network Properties dialog box.
Click the Settings tab, set the emulation to VT100, and then click OK.
Note: Please use the DB-9 to RJ-45 Console cable which we provide together with this
device. Use the DB-9 to RJ-45 Console cable from other vendors maybe can’t access
this device.
Note: Please use the DB-9 to RJ-45 Console cable which we provide together with this
device. Use the DB-9 to RJ-45 Console cable from other vendors maybe can’t access
this device.
3.3 Setting Terminal Parameter (SecureCRT from VanDyke Software):
Install the SecureCRT software on PC. Set SecureCRT Serial terminal parameters.
Step 1: Click “Quick Connect” button to enter the SecureCRT quick connect window.
Step 2: Choose the “Serial” as the Protocol.
Step 3: In the Port item, please choose specified COM port that the PC is using. (Here we take
COM4 as an example.)
Step 4: Set Baud rate to 115200, Data bits to 8, Parity to None, Stop bits to 1, and Flow control
to XON/XOFF. Then click Connect button to enter the Serial display interface.
Step 5: If the network advice is connected with PC via Serial cable, you could see the command
line interface (CLI) when you push down the “Enter” button of the PC.
