Hardware Overview
Front Panel Ports
Front Panel LEDs
SS5850-48S8C-DC
2
EN
Ports Description
SFP28
QSFP28
SFP28 ports for 1/10G transceivers
QSFP28 ports for 40/100G transceivers
ID
SYS
ID indication function enable.
Blue
On
On
On
On
O
Green
O
O
Amber
Loop Blinking
O
ID indication function disable.
The system is normally running.
Alarm or error occurs in the system.
No power or the system is not running or abnormality.
MGT
Breakout
Green
Port is linked.
Port is not linked.
One or more 100G/40G ports are breakout.
None of the 100G/40G ports is breakout.
LEDs State
Description
25G SFP28
100G QSFP28
S5850-48S8C-DC
Breakout
ID
MGT
SYS
25G SFP28
100G QSFP28
