WARNING: Do not install power cables while the power is on.
1. Plug the AC power cord into the power port on the back of the switch.
2. Connect the other end of the power cord to a power source.
(The S5850-48S8C-DC power port is dierent from the power ports of S5850-48S8C and
S5850-48B8C. )
Connecting the Power
1. Plug the compatible SFP28 transceiver into the SFP28 port.
2. Connect a ber optic cable to the ber transceiver. Then connect the other end of the cable to
other ber devices.
Connecting the SFP28 Ports
8
EN
