CAP-600
19A
MAIN PARTS LISTING FOR
MODEL ES150B
ITEM
NO.
PART
NO.
DESCRIPTION QTY
1
91501-1310025
BOLT, M10 X 25 10
2
9252615-101000-0
COPPER WASHER 10
3
701310A1-57061 REAR BEARING COVER
1
4
70131B81-57670
TUBE & BRTHR. ASSY. 1
4a
70131BA1-57670
TUBE, BREATHER 1
4b
CCC1697
BREATHER, ASSY. 1
5
701310A1-57590 REAR COVER OIL BAFFLE
1
6
701310A1-57070 REAR BRG CVR GASKET
1
7
70123-57190-4010
CRANKCASE OIL CAP 1
8
VH1470
GAUGE SET BOLT 4
9
701210A1-57740
OIL GLASS & COVER 1
9a
701210A1-57700
OIL COVER ASSY 1
10
70124-57750
OIL COVER GLASS 1
11
701210A1-57730
GAUGE COVER SEAL 1
12
9156310-400800
CRANKCASE OIL PLUG 1
13
701312A3-57010
CRANKCASE 1
14
9354504-30310
BEARING #30310 1
15
701312A1-56011
CRANKSHAFT 1
16
701312A1-56032 CRANKSHAFT CTR. WGT.
2
17
701312A1-56830
CTR WGT LK WASHER 2
18
701312A1-56811
CTR WGT MGT BOLT 2
19
701310A1-56060
V-PULLEY KEY 1
20
9354501-32210
BEARING #32210 1
21
70135-57950 FRONT BEARING GASKET
1
22
701310A1-57080
FRONT OIL SEAL 1
23
701312A1-57030 FRONT BEARING COVER
1
24
701312A1-76011 COMPRESSOR PULLEY
1
25
70131283-76310
COMP PULLEY FAN 1
26
9253113-100800-8
WASHER 6
27
9150113-1108030-5202
BOLT 6
28
701210A1-76210
PULLEY THRUST WASHER
1
29
9253113-101200-8
SPRING WASHER 1
30
9150113-1112050-5608
BOLT 1
31
701312A1-51030
CYL & CASE PACKING 3
32
701312A1-51810
CYL & CASE BOLT 12
33
701312A1-61281
OIL SPLASH DIPPER 3
34
9250113-120800-538
NUT 3
35
701212A1-61090
CONN.ROD CRANK PIN METL
6
36
701212A1-61200
CONN.ROD ASS’Y 3
37
70125-61250 CONN.ROD ASS’Y BOLT
6
38
501312A1-61081
CONN.ROD CRANK PIN METL
3
39
701212A1-61070 PISTON PIN SNAP RING
6
40
701212A1-61120
PISTON PIN 3
41
701312A1-61010
PISTON 3
42
701212A1-61050
OIL CONTROL RING 6
43
701212A1-61030
COMPRESSION RING 6
44
701312A3-51010
CYLINDER 3
45
92501-131200
NUT 12
46
701312A3-11020
CYL & HEAD GASKET 3
47
9250113-121200-538
BOLT 12
48
701312A3-11010
CYLINDER HEAD 3
49
701212A1-11110
I/O VALVE SEAT GASKET
6
ITEM
NO.
PART
NO.
DESCRIPTION QTY
50
701212A1-31023 INLET VALVE RECEIVER 3
51
701212A1-31070
INLET VALVE SPRING 3
52
501212A1-31030
PLATE, INLET VALVE 3
53
701212A1-31010
INTER VALVE SEAT 3
54
701212A1-31090
I. VALVE UNLOAD FORK GUIDE
3
55
701212A1-11230
UNLOADING SPRING 3
56
701212A1-31080
I.VALVE UNLOAD FORK 3
57
9250413-151200-532
SLOTTED NUT 3
58
9360187-350217
O-RING P#22A 3
59
701212A1-11220
UNLOADING PISTON 3
60
9360287-310644
O-RING G#65 3
61
701212A1-11151
I. VALVE PUSH COVER 3
62
91501-1310025
BOLT 3
63
90112-100101
SCREW PLUG 24
64
70124-41810
BOLT 3
65
701212A1-41012
OUTLET VALVE SEAT 3
66
701212A1-41075 OUTLET VALVE SPRING
3
67
701212A1-41025 OUTLET VALVE RECEIVR
9
68
92501-231000
NUT 3
69
9360287-310644
VITON O-RING G#65 6
70
701212A1-11451 O. VALVE PUSH COVER
3
71
701312A1-87032
DIST. MANIFOLD #C 3
72
70135-87101
COMP.BODY DIS. PIPING
ASSEMBLY
1
73
701312A1-87022
DIST. MANIFOLD #B 1
74
701312A2-87100
COMP.BODY DIS. PIPING
ASSEMBLY
1
75
701312A2-87011
DIST. MANIFOLD #A 1
76
70125-41030
PLATE, OUTLET VALVE 1
77
701212A1-41001
OUTLET, VALVE ASSY. 3
78
701212A1-31000
INLET, VALVE ASSY. 3
79
701312A1-66000
AIR STRAINER ASSY. 3
80
701208A1-66110
AIR STRAINER FILTER 3
