FScurtis CA series - Rebuild Kits and Parts Lists

CAP-600
7
• REBUILD KITS
AIR COOLED SINGLE STAGE MODELS
ES03 ES05
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
1 70111-66140 Filter Element 1 70111-66140 Filter Element
2 70111-31030 Valve Disc 2 70112-31030 Valve Disc
1 70111-31070 Spring 1 70112-31070 Spring
1 70111-41070 Spring 1 70112-41070 Spring
1 70111-11461 Gasket 2 70112-61030 Comp. Ring
1 70111-11612 Head Gasket 1 70112-61050 Oil Ring
2 70111-61030 Comp. Ring 1 70112-11612 Head Gasket
1 70111-61050 Oil Ring 1 70112-51610 Crankcase Gasket
1 70111-57970 Bottom Cover Gasket 1 70112-57950 Front Cover Gasket
1 70111-57950 Front bearing cover gasket 1 70112-57960 Rear Cover Gasket
1 70111-57080 Front Oil Seal 1 70112-57080 Oil Seal
1 70111-57960 Rear Cover Gasket 12 92521-190800 Copper Washer
CF1299
10 92521-190600 Copper Washer
CF1237
1 70112-11461 Copper Gasket
ES06 ES10, ES10P ES20
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
2 70111-66140 Filter Element 2 70111-66140 Filter Element 3 70111-66140 Filter Element
4 70111-31030 Valve Disc 4 70112-31030 Disc 6 70112-31030 Disc
2 70111-31070 Spring 2 70112-31070 Spring 3 70112-31070 Spring
2 70111-41070 Spring 2 70112-41070 Spring 3 70112-41070 Spring
2 70111-11461 Gasket 4 70112-61030 Compression Ring 6 70112-61030 Compression Ring
2 70111-11612 Head Gasket 2 70112-61050 Oil Ring 3 70112-61050 Oil Ring
2 70121-51610 Crankcase Gasket 2 70112-11612 Head Gasket 3 70112-11612 Head Gasket
4 70111-61030 Comp. Ring 2 70112-51610 Crankcase Gasket 3 70112-51610 Crankcase Gasket
2 70111-61050 Oil Ring 1 70122-57950 Front Cover Gasket 1 70122-57950 Front Cover Gasket
1 70121-57950 Front Cover Gasket 1 70122-57960 Rear Cover Gasket 1 70122-57960 Rear Cover Gasket
1 70111-57960 Rear Cover Gasket 1 70122-57080 Front Oil Seal 1 70122-57080 Front Oil Seal
1 70121-57970 Bottom Cover Gasket 24 92521-190800 Copper Washer 26 92521-190800 Copper Washer
24 92521-190600 Copper Washer 2 70112-11461 Copper Gasket 3 70112-11461 Copper Gasket
CF1302 CF1238 CF1239
ES-30 ES-50 ES-100 ES-150 ES-150A
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
CF1246 REBUILD KIT INCLUDES:
CF1252
PREVENTATIVE MAINTENANCE
KIT INCLUDES
CF1252
PREVENTATIVE MAINTENANCE
KIT INCLUDES
CF1252
PREVENTATIVE MAINTENANCE
KIT INCLUDES
CF1252
PREVENTATIVE MAINTENANCE
KIT INCLUDES
2 70123-66140 Filter Kit
4 70123-31030 Disc
3 70123-66140 Filter Element 3 70123-66140 Filter Element 3 70123-66140 Filter Element 3 70123-66140 Filter Element
2 70123-31070 Spring
2 70123-41070 Spring
CF1245
VALVE / GASKET MAINT. KIT INCLUDES
CF1243
VALVE / GASKET MAINT. KIT INCLUDES:
CF1241
VALVE / GASKET MAINT. KIT INCLUDES:
CF1320
VALVE / GASKET MAINT. KIT INCLUDES:
4 70123-61030 Compression Ring
4 70123-61050 Oil Ring 6 70123-31030 Disc 6 70124-31030 Disc 6 70125-31030 Disc 3 70125-31030 Disc I / V
4 70123-11110 Seat Gasket 3 70123-31070 Spring 3 70124-31070 Spring 3 70125-31070 Spring 3 70125-31070 Spring
2 70123-11612 Head Gasket 3 70123-41070 Spring 3 70124-41070 Spring 9 70125-41074 Spring 9 701212A1-41075 Spring
2 70123-51610 Crankcase Gasket 6 70123-11110 Seat Gasket 6 70124-11110 Seat Gasket 6 70125-11110 Seat Gasket 6 70125-11110 Seat Gasket
1 70123-57950 Front Cover Gasket 3 70123-11612 Head Gasket 3 70124-11612 Head Gasket 3 70125-87510 Manifold Gasket 3 70125-41030 Disc O / V
1 70123-57960-01 Rear Cover Gasket 3 70125-11610 Head Gasket 3 70125-11612 Head Gasket
1 70123-57080 Front Oil Seal ** 70125-11612 Head Gasket
*2 70123-61081 Bushing
2 70123-61090 Set, Rod Bearing
CF1244 REBUILD KIT INCLUDES: CF1242 REBUILD KIT INCLUDES: CF1244 REBUILD KIT INCLUDES: CF1244 REBUILD KIT INCLUDES:
26 92521-191000 Copper Washer
1 70123-57080 Front Oil Seal 1 70124-57950
Frt. Brg. Cvr. Gasket
1 70134-57080 Front Oil Seal 1 70134-57080 Front Oil Seal
6 70123-61030 Compr.Ring 6 70124-61030 Compr.Ring 6 70125-61030 Compression Ring 6 70125-61030 Compression Ring
6 70123-61050 Oil Ring 6 70124-61050 Oil Ring 6 70125-61050 Oil Ring 6 70125-61050 Oil Ring
*3 70123-61081 Bushing 3 70124-61080 Bushing *3 70125-61081 Bushing *3 70125-61081 Bushing
3 70123-61090 Set, Rod Bearing 6 70124-61090 Set, Rod Bearing 3 70125-61090 Set, Bearing 6 70125-61090 Set, Bearing
3 70123-51610 Crankcase Gasket 3 70124-51610 Crankcase Gasket *3 70135-51610 Crankcase Gasket *3 70135-51610 Crankcase Gasket
1 70123-57950
Frt. Brg. Cvr. Gasket
1 70134-57080 Front Oil Seal 1 70135-57950 Frt. Brg.Cvr Gasket 1 70135-57950 Frt. Brg.Cvr Gasket
1 70133-57960
Rear Brg. Cvr. Gasket
1 70134-57960
Rear Brg. Cvr. Gasket
1 70134-57960 Rear Brg.Cvr Gasket 1 70134-57960 Rear Brg.Cvr Gasket
34
92521-191000
Copper Washer
34
92521-191000
Copper Washer
24 92521-191000 Copper Washer 24 92521-191000 Copper Washer
* WARNING – THESE ITEMS INTERCHANGE WITH PARTS ON SERIAL #3020000 & HIGHER ONLY.
CONTACT FACTORY FOR EARLIER SERIES.
** USE WITH SERIAL #A311XXXX AND LATER
.
70135-11610 REPLACES 70125-11610
