CAP-600
8
• REBUILD KITS
AIR COOLED TWO STAGE MODELS
E-35
PART
NO.
CONSISTS OF:
CF1306
PREVENTATIVE MAINTENANCE
KIT INCLUDES:
1 70152-66141 Element
CF1307
VALVE/GASKET MAINT KIT
INCLUDES:
4 70152-31030 Disc
2 70152-32030 Disc
4 70152-31070 Spring
2 70152-32070 Spring
1 70152-11612 Head Gasket
1 70152-31120 Seat Gasket
1 70152-11622 Seat Gasket
CF1308 REBUILD KIT INCLUDES:
1 70152-51610 Case Gasket
1 70152-57960 Rear Cover Gasket
2 70152-61030 Comp. Ring
1 70152-61050 Oil Ring
1 70152-61080 Bushing (L.P.)
1 70152-62080 Bushing (H.P.)
2 70152-61090 Rod Bearing Set
3 70152-62030 Compression Ring
1 70152-62050 Oil Ring
1 70152-57950 Front Cover Gasket
1 70127-57080 Front Oil Seal
6 92521-190800 Copper Washer
E-11 E-23
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
CF1250 1 70111-66140 Filter Element CF1251 2 70111-66140 Filter Element
2 70112-31030 Disc 4 70112-31030 Disc
2 70162-32030 Disc 2 70111-31030 Disc
1 70112-31070 Spring 2 70112-31070 Spring
1 70162-42070 Spring 2 70112-41070 Spring
1 70112-41070 Spring 1 70172-32070 Spring
1 70162-32070 Spring 1 70172-42070 Spring
2 70112-61030 Compression Ring 4 70112-61030 Compression Ring
1 70112-61050 Oil Ring 2 70112-61050 Oil Ring
2 70162-62030 Compression Ring 2 70111-61030 Compression Ring
2 70162-62050 Oil Ring 2 70111-61050 Oil Ring
1 70112-11612 Head Gasket (1
st
) 2 70112-11612 Head Gasket (1
st
)
1 70162-12610 Head Gasket (2
nd
) 1 70111-11612 Head Gasket (2
nd
)
2 70112-51610 Crankcase Gasket 3 70112-51610 Crankcase Gasket
1 70122-57950 Front Cover Gasket 1 70122-57950 Front Cover Gasket
1 70122-57960 Rear Cover Gasket 1 70122-57960 Rear Cover Gasket
1 70122-57080 Front Oil Seal 1 70122-57080 Front Oil Seal
24 92521-190800 Copper Washer 32 92521-190800 Copper Washer
1 70112-11461 Copper Gasket 1 70111-11461 Copper Gasket
2 70112-11461 Copper Gasket
E-57 E-50 E-71 E-15
PART NO. CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
PART
NO.
CONSISTS OF:
CF1291
PREVENTATIVE MAINTENANCE KIT
INCLUDES
CF1315
PREVENTATIVE MAINTENANCE
KIT INCLUDES:
CF1315
PREVENTATIVE MAINTENANCE
KIT INCLUDES:
CF1315
PREVENTATIVE MAINTENANCE
KIT INCLUDES:
1 70153-66142 Element 2 70123-66140 Element 2 70123-66140 Element 2 70123-66140 Element
CF1292
VALVE/GASKET MAINT KIT
INCLUDES:
CF1253
VALVE/GASKET MAINT KIT
INCLUDES:
CF1255
VALVE/GASKET MAINT KIT
INCLUDES:
CF1257
VALVE/GASKET MAINT KIT
INCLUDES:
4 70153-31032 Disc 6 70123-31030 Disc 4 70124-31030 Disc 4 70125-31030 Disc
2 70153-32032 Disc 3 70123-31070 Spring 2 70123-31030 Disc 2 70175-42030 Disc
4 70153-31072 Spring 3 70123-41070 Spring 2 70124-31070 Spring 2 70125-31070 Spring
2 70153-32072 Spring 6 70123-11110 Seat Gasket 1 70123-31070 Spring 1 70124-31070 Spring
1 70153-31120 Head Gasket 3 70123-11612 Head Gasket 2 70124-41070 Spring 6 70125-41070 Spring
1 70153-11612 Seat Gasket 1 70123-41070 Spring 1 70124-41072 Spring
1 70153-11622 Seat Gasket 4 70124-11110 Seat Gasket 4 70125-11110 Seat Gasket
2 70123-11110 Seat Gasket 2 70124-11110 Seat Gasket
2 70124-11612 Head Gasket 4 70125-87510 Manifold Gasket
1 70123-11612 Head Gasket 2 70125-11610 Head Gasket
1 70124-11612 Head Gasket
** 70135-11610 Head Gasket
CF1293 REBUILD KIT INCLUDES: CF1254 REBUILD KIT INCLUDES: CF1256 REBUILD KIT INCLUDES: CF1258 REBUILD KIT INCLUDES:
1 70153-57951 Front Bearing Gasket 1 70123-57950 Front Bearing Gasket 1 70124-57950 Front Bearing Gasket 4 70125-61030 Compression Ring
2 70124-61030 Compression Ring 4 70123-61030 Compression Ring 4 70124-61030 Compression Ring 4 70125-61050 Oil Ring
2 70124-61050 Oil Ring 4 70123-61050 Oil Rings 4 70124-61050 Oil Ring 3 70124-61030 Compression Ring
3 70153-62030 Compression Ring 3 70112-61030 Compression Ring 3 70123-61030 Compression Ring 2 70124-61050 Oil Ring
1 70153-62050 Oil Ring 1 70112-61050 Oil Ring 2 70123-61050 Oil Ring 2 70125-61081 Bushing
1 70153-61081 Bushing (L.P.) 2 70123-61081 Bushing 2 70124-61080 Bushing 3 70125-61090 Rod Bearing (2 Halves)
1 70153-62081 Bushing (H.P.) 1 93503TA1725 Needle Bearing 1 70174-62081 Bushing 3 70135-51610 Gasket
4 70153-61090 Rod Bearing (Halves) 6 70123-61090 Rod Bearing (Halves) 3 70124-51610 Gasket 1 70134-57080 Oil Seal
1 70153-51611 Case Gasket 3 70123-51610 Crankcase Gasket 1 70134-57080 Oil Seal 1 70135-57950 Front Bearing Gasket
1 70123-57080 Oil Seat 1 70123-57080 Oil Seal 6 70124-61090 Bearing (Halves) 1 70134-57960 Rear Bearing Gasket
1 70153-57961 Rear Bearing Gasket 1 70133-57960 Rear Bearing Gasket 1 70134-57960 Rear Bearing Gasket 24 92521-191200 Copper Washer
26 92521-191000 Copper Washer 34 92521-191000 Copper Washer 34 92521-191000 Copper Washer 1 93503-NK28/30 Needle Bearing ***
1 70173-62080 Bushing 1 70175-62080 Bushing ****
* WARNING – THESE ITEMS INTERCHANGE WITH PARTS ON SERIAL #3020000 & HIGHER ONLY.
CONTACT FACTORY FOR EARLIER SERIES.
** USE WITH SERIAL #A311XXXX AND LATER
.
70135-11610 REPLACES 70125-11610
*** USE WITH SERIAL #A409XXXX AND LATER
**** USE FOR UNITS PRIOR TO SERIAL #A409XXXX
