CAP-600
MAIN PARTS LISTING FOR
TWO STAGE MODELS E-50 & E-71 (CONTINUED)
MODEL E-50 MODEL E-71
DESCRIPTION
QTY
1
st
Stage
QTY
2
nd
Stage
QTY
1
st
Stage
QTY
2
nd
Stage
Valves & Unloaders
12B Outlet Valve Spring 2 70123-41070 1 70123-41070 2 70124-41070 1 70123-41070
13 Outlet Valve Bolt 2 70123-41810 1 70123-41810 2 70124-41810 1 70123-41810
14 Nut (Outlet Valve) 2 92502-230800 1 92502-230800 2 92502-230800 1 92502-230800
15 Inlet Valve Push Cover 2 70123-11150 1 70123-11150 2 70124-11150 1 70123-11150
16 O-ring G-40(Inlet Valve) 2 93602-810040 1 93602-810040 2 93602-810055 1 93602-810055
17 Viton O-ring G-40 (Outlet Valve) 2 93602-870040 1 93602-870040 2 93602-870055 1 93602-870040
18 Unloading Piston 2 70123-11220 1 70123-11220 2 70124-11220 1 70123-11220
19 O-ring P-20 2 93601-810020 1 93601-870020 2 93601-810021 1 93601-870020
20 Outlet Valve Push Cover 2 70123-11450 1 70123-11450 2 70124-11450 1 70123-11450
20A Iinterstage Safety Valve (E71 only) - N/A - N/A 1 93132-15006-40101 - N/A
Cylinders
2
21 Cylinder Head (1
st
) 2 70123-11010 2 70124-11010
22 Cylinder & Head Gasket 2 70123-11612 1 70123-11612 2 70124-11612 1 70123-11612
23 Cylinder (1
st
) 2 70123-51012 2 70124-51011
23A S/N A311xxxx & Later Use 2 70123-51012 2 70124-51011
24 Cylinder & Case Gasket 2 70123-51610 1 70123-51610 2 70124-51610 1 70124-51610
25 Compression Ring (1
st
) 4 70123-61030 4 70124-61030
26 Oil Control Ring (1
st
) 4 70123-61050 4 70124-61050
27 Piston (1
st
) 2 70123-61011 2 70124-61011-1
27A S/N 3020000 & Later Use 2 70123-61011 2 70124-61011-1
28 Piston Snap Ring 4 70123-61070 2 70123-61070 4 70124-61070 2 70124-61070
29 Piston Pin (1
st
) 2 70123-61120 2 70124-61120
30 Con’cting Rod Pist. Pin Bushing 2 70123-61081 1 70173-62080 2 70124-61080 1 70174-62081
30A Bushing S/N 3020000 & Later use 2 70123-61081
30B Nedl Brg.S/N A303XXXX&LatrUse 1 93503-RNA6903R
30C Nedl Brg.(2
nd
)S/N A405XXXX&Latr 1 93503-TA1725
31 Connecting Rod Assy 2 70123-61200 1 70173-62200 2 70124-61201 1 70174-62202
31B
Conn. Rod Assy., 2
nd
Stage S/N
A405XXXX & Later Use
1 70173-62200
32 Connecting Rod Crank Pin Metal 4 70123-61090 2 70123-61090 4 70124-61090 2 70124-61090
33 Connecting Rod Bolt 4 70125-61250 2 70125-61250 4 70125-61250 2 70125-61250
34 Oil Splash Dipper 2 70122-61282 1 70132-61290 2 70134-61281 1 70134-61290
35 Oil Splash Dipper Bolt 2 91507-2304012 1 91507-2304012 2 91507-2304012 1 91507-2304012
36 Cylinder Head (2
nd
) 1 70123-11010 1 70174-12010
37 Cylinder (2
nd
) 1 70173-52010 1 70174-52011
37A Cyl (2
nd
),S/N 3020000 & Later Use 1 70174-52011
38 Compression Ring (2
nd
) 3 70112-61030 3 70123-61030
39 Oil Control Ring (2
nd
) 1 70112-61050 2 70123-61050
40 Piston (2
nd
) 1 70173-62010-1 1 70174-62010-1
41 Piston Pin (2
nd
) 1 70173-62120 1 70174-62120
Crankcase & Crank Assembly
42 Crankshaft 1 70133-56011 1 70134-56010
43 Crankshaft, Counterweight - 1 70134-56030
44 Counterweight Lock Washer - 2 70124-56830
45 Counterweight Mtg. Bolt - 2 70124-56810
46 Crankcase 1 70133-57010-4024 1 70134-57010-4024
47 Front Bearing Cover 1 70133-57030 1 70134-57030
48 Front Bearing Cover Gasket 1 70123-57950 1 70124-57950
49 Rear Bearing Cover 1 70133-57061 1 70134-57061
49A Rear Brg Cvr, S/N 3020000 & Later 1 70133-57061 1 70134-57061
50 Rear Brg Cvr Gasket 1 70133-57960 1 70134-57960
51 Front Bearing 1 93501-6306 1 93502-32210
52 Rear Bearing 1 93501-6306 1 93502-32210
53 Front Oil Seal 1 70123-57080 1 70134-57080
54 V-Pulley Pin 1 70123-56061 1 70134-56060
55A Compressor Fan - 1 70124-76310
55B Compressor Pulley 1 70133-76010 1 70134-76011
56 Compressor Pulley Washer 1 92521-232000 1 70124-76210
57 Compressor Pulley Set Bolt 1 91501-1312030 1 91501-1312040
58 O-Ring (Oil Level Glass) 1 93602-81260-3065 - - - -
59 Screw In Oil Level Glass 1 70A109B1-57702 - - - -
60 Crankcase Oil Cap 1 CCC1257 1 CCC1257
61 Crankcase Oil Plug 1 90112-100404 1 90112-100404
62 Breather Assembly 1 CCC1375 1 CCC1258
66A Air Strainer Assembly 2 70123-66000 2 70123-66000
67 Air Strainer Filter 2 70123-66140 2 70123-66140
69 Outlet Pipe Joint B 1 70123-87020 1 70174-87020
70A Comp.body.discharg.pipe.assy. 1
st
1 70133-87101 short 1 70134-87101 short
70B Comp.body.discharg.pipe.assy. 1
st
- -
70C Comp.body.discharg.pipe.assy.2nd - -
70D Comp.body.discharg.pipe.assy.2nd 1 70173-87300 long 1 70174-87300 long
71 Outlet Pipe Joint A 2 70123-87010 3 70124-87010
72 Outlet Pipe Joint D 1 70173-87010
73 Outlet Pipe Joint C
74 Gasket Manifold - -
75 Oil Level Glass Gasket 1 701210A1-57730 1 701210A1-57730
76 Oil Level Glass Assembly 1 701210A1-57700 1 701210A1-57700
77 Oil Level Glass Push Cover 1 701210A1-57740 1 701210A1-57740
78 Screw, Metric Pan Head 4 VH1470 4 VH1470
23
