CAP-600
25B
MAIN PARTS LISTING FOR
TWO STAGE MODEL E-25
Item
No.
Description
Model E-25
Qty
Req.
1
st
Stage
Qty
Req.
2
nd
Stage
1 CRANKCASE 1
70131EB2-57010
2 OIL SIGHT GLASS GASKET 1
70124-57730
3 OIL SIGHT GLASS ASSY. 1
70124-57700
4 OIL SIGHT GLASS PUSH COVER 1
70124-57740
5 OIL SIGHT GLASS BOLT; M5 x L20, Gr.8.8 4
91507-2305020
6 BOLT M12*1.25*L10 1
9152813-1Z12010
7 OIL NOZZLE 2
703213A1-561070
8 PIPE 1
9011023-1604604
9 PIPE CAP 1
9092017-1304000
10 CRANK SHAFT 1
70131EB2-56010
11 FRONT & REAR BEARING 2
93501-33112
12 REAR BEARING COVER GASKET 1
70178-57070
13 REAR BEARING COVER 1
70131EB2-57060
14 REAR OIL SEAL 1
70131EB2-57090
15 CENTRIFUGAL FAN LOCK WASHER; M10 12
92521-231000
16 CENTRIFUGAL FAN BOLT; M10 X L30, Gr.8.8 12
91501-2310030-8
17 FIX PLATE 1
70131EB2-57930
18 PRESSURE SWITCH 1
93301-990005
19 O-RING (OIL FILL CAP) 1
93601-810018
20 OIL FILL CAP 1
70123-57190
21 CYLINDER – CASE GASKET (2
)
1 70178-52030
22 CONNECTING ROD CRANK PIN 6
70178-61090
23 CONNECTING ROD BOLT 6
70178-61250
24 LOCKWASHER (M12) 6
92522-131200
25 NUT; (M12) 6
92501-131200-8
26 CONNECTING ROD 3
70131EB2-61210
27 CONNECTING ROD – PISTON PIN NEEDLE BEARING 3
93501-3230
28 PISTON PIN SNAP RING 6
93610-130032
29 PISTON (2
)
1
70131EB2-62120
30 PISTON (2
)
1
70131EB2-62010
31 OIL CONTROL RING (2
)
2
70178-62050
32 COMPRESSION RING (2
)
3
70178-62030
33 CYLINDER BOLT (1
); M16 x L46, Gr. 8.8 12
91525-1316045-8
34 CYLINDER LOCK WASHER; M16 x L46, Gr. 8.8 13
92522-131600
35 CYLINDER NUT; M16 12
92501-131600
36 CYLINDER (2
)
1
70178-52010
37 VALVE – CYLINDER GASKET (2
)
1
70178-31240
38 INLET & OUTLET VALVE GASKET (2
)
2
70125-11110
39 OUTLET VALVE BOLT; M10 X L50, Gr. 8.8 1
9152613-1110050
40 OUTLET VALVE SEAT (2
)
1
70125-41011
41 OUTLET VALVE SPRING (2
)
3
70125-41074
42 OUTLET VALVE RECEIVER (2
)
1
701212A1-41026
43 OUTLET VALVE PLATE (2
)
1
501212A1-41032
44 NUT; M10 (Outlet Valve) 6
92501-231000
45 INLET VALVE RECEIVER (2
)
1
70125-31023
46 INLET VALVE PLATE (2
)
1
50125-31030
47 INLET VALVE SPRING (2
)
1
70125-31070
48 INLET VALVE SEAT (2
)
1
70125-31010
49 INLET VALVE UNLOADER FORK (2
)
1
70125-31080
50 UNLOADER SPRING 3
70125-11230
To Next Page
