MAIN PARTS LISTING FOR CAP600
TWO STAGE MODEL E-25
25D
Item
No.
Description
Model E-25
Qty
Req
1
st
Stage
Qty
Req
2
nd
Stage
101 PIPING-INTERCOOLER BOLT; M10 x L30, Gr. 8.8
14 91513-1310030-8
102 PIPING- INTERCOOLER GASKET
2 70178-87090
103 DISCHARGE PIPING ASSEMBLY
1 70178-87100
104 MIDDLE INTERCOOLER ASSEMBLY
1 70131EB1-71000C
105 COMPRESSOR FAN
1 70178-76310
106 COMPRESSOR FAN WASHER, M8
6 92521-230800
107 COMPRESSOR FAN LOCK WASHER, M8
6 92522-130800
108 COMPRESSOR FAN BOLT; M8 x L30, Gr. 8.8
6 91501-92308030-8
109 PIPING-HEAD GASKET
2 70178-87130-1
110 DISCHARGE PIPING ASSEMBLY
1 70178-87200
111 GEAR PUMP COUPLING
1 703213A1-27110
112 BOLT; M6*15
1 91501-2306015
113 NUT; M6
1 92501-130600
114 GEAR PUMP HOUSING GASKET
1 703213A1-27020
115 GEAR PUMP HOUSING
1 70131EB2-27010
116 STEEL BALL
1 9980113-20036
117 BALL VALVE RECEIVER
1 703213A1-28090
118 PRESSURE GAUGE (0~10K)
1 9320611-2032213
119 BALL VALVE SPRING
1 703213A1-28080
120 REGULATOR SEALING
1 703213A1-28110
121 REGULATOR ADJUST NUT
1 703213A1-28130
122 REGULATOR ADJUST BOLT
1 703213A1-28120
123 GEAR PUMP SHAFT
1 703213A1-27070
124 DRIVE GEAR RING
1 703213A1-27130
125 DRIVE GEAR
1 703213A1-27050
126 DIRVEN GEAR
1 703213A1-27060
127 O-RING
1 9360281-31044
128 GEAR PUMP HOUSING COVER
1 70131EB2-27030
129 LOCK WASHER, M10
3 92522-131000
130 BOLT; M10*30
3 91501-2310030
131 COPPER PIPE JOINT
1 7992013-2204050
132 PUMP CONNECTING TUBE
1 70131EB2-27080
133 STRAINER PLUG
1 703213A1-28530
134 FEED OIL FILTER ASSEMBLY
1 703213A1-28500
135 BREATHER ASSEMBLY (RUBBER)
1 701312A1-57601
136 BREATHER TUBE
1 70131BA1-57670
137 ELBOW 45º
1 9010311-1304304
138 NIPPLE ½
1 9011013-1304304
139 AIR FILTER ASSEMBLY
2 70178-66000

