CAP-600
27
MAIN PARTS LISTING FOR
AIR COOLED TWO STAGE MODEL E-35
(FORMERLY B-1)
DESCRIPTION QTY PART NO.
1. Discharge Elbow 1 70123-87050
2. Discharge Elbow Nut (Not Shown) 1 79922-130606
3. Cylinder Head Bolt 6 91501-1310085
4. Spring Washer 6 92522-130800
5. Cylinder Head 1 70152-11010
6. Unloading Tee * # 1 79922-150101
7. Bolt 2 91521-1306025
8. Spring Washer 2 92522-130600
9. Upper Cover 1 70153-11270
10. Upper Cover Gasket 1 70153-11641
11.
Unloader Assembly (1
s
t
)(Includes 12-
16)
1 70152-11201
12. Unloading Piston 1 70153-11222
13. Unloading Spring 1 70153-11231
14. Unloading Cylinder 1 70153-11211
15. Unloading Fork (1
s
t
) 1 70152-31080
16. Bolt 1 91501-1306015
17. Cylinder Head Valve Seat Gasket 1 70152-11612
18. Valve Plate Assembly (Includes 19-27) 1 70152-31000
19. Valve Seat Bolt 3 91521-1305012
20. Valve Seat (Upper) 1 70152-31010
21. Valve Seat Gasket 1 70152-31120
22. Valve Plate (1
s
t
) 4 70152-31030
23. Valve Plate Spring (1
s
t
) 4 70152-31070
24. Valve Plate (2
n
d
) 2 70152-32030
25. Valve Plate Spring (2
n
d
) 2 70152-32070
26. Valve Seat (Bottom) 1 70152-31020
27. Nut 1 92501-230500
28. Cylinder-Valve Seat Gasket 1 70152-11622
29. Cylinder 1 70152-51010
30. Cylinder Crankcase Gasket 1 70152-51610
31. Bolt 11 91501-1310030
32. Copper Washer 6 92521-190800
33. Crankcase Oil Cap 1
70101-57190-4010
34. Oil Cap O-Ring 1 93601-810016
35. Crankcase 1 70152-57010
36. Bearing #6025 (Front & Rear) 2 93501-6205
37. Rear Cover Gasket 1 70152-57960
38. Rear Cover 1 70152-57060
39. Rear Cover Bolt 3 91521-1308030
40. Copper Washer 7 92521-190800
41. Oil Level Gauge & Gauge Cover 1 70111-57700
42. Gauge Cover Seal 1 70111-57730
43. Crankcase Oil Plug (1/4” NPT) 1 90112-100303
44. Inter-Cooler Bolt 3 91521-1308050
45. Gasket 1 70152-71612
46. Inter-Cooler Body 1 70152-71110
46A. Gasket, Copper 1 70152-12280
DESCRIPTION QTY PART NO.
47. Inter-Cooler Body Gasket 1 70152-71622
48. Inter-Cooler Cover 1 70152-71160
49. Spring Washer 4 92522-130600
50. Bolt 4 91501-1306016
51. Compression Ring (1
s
t
) 2 70152-61030
52. Oil Control Ring (1
s
t
) 1 70152-61050
53. Piston (1
s
t
) 1 70152-61010
54. Piston Snap Ring 4 70152-61070
55. Connection Rod Assembly (1
s
t
) 1 70152-61200
56. Piston Pin Bush (1
s
t
) 1 70152-61080
57. Connecting Rod Assembly (2
n
d
) 1 70152-62200
58. Piston Pin Bush (2
n
d
) 1 70152-62080
59. Crank Pin Metal (Rod Bearing 2 Halves) 2 70152-61090
60. Crankshaft 1 70152-56010
61. Piston Pin (1
s
t
) 1 70152-61120
62. Compression Ring (2
n
d
) 3 70152-62030
63. Piston Pin (2
n
d
) 1 70152-62120
64. Oil Control Ring (2
n
d
) 1 70152-62050
65. Piston (2
n
d
) 1 70152-62010
66. Breather Assembly 1
CCC1375
67. V-Pulley Pin 1 70112-56060
68. Nut (Connecting Rod) 4 92501-130800
69. Spring Washer (Connecting Rod) 4 92522-130800
70. Bolt (Connecting Rod) 4 70152-61250
71. Front Cover Gasket 1 70152-57950
72. Front Cover 1 70152-57030
73. Front Oil Seal 1 70127-57080
74. Copper Washer 7 92521-190800
75. Bolt 4 91501-1310030
76. Compressor Pulley 1 70152-76010
77. Compressor Pulley Thrust Washer 1 70112-76210
78. Bolt 1 91501-1308025
79. Unloading Elbow * # 1 79926-150101
80.
Unloader Assembly (2
n
d
)(Includes 81-
85)
1 70152-12200
81. Unloader Cover (2
n
d
) 1 70103-11271
82. Viton O-Ring Unloader (2
n
d
) 1 93601-870009
83. Unloading Piston (2
n
d
) 1 70152-12221
84. Unloading Spring (2
n
d
) 1 70103-11230
85. Unloader Body 1 70153-12200
86. Air Strainer Assembly (Includes 87-92) 1 70152-66001
87. Air Strainer Cover Gasket 1 70152-66131
88. Air Strainer Cover 1 70153-66120
89. Air Strainer Bolt 1 70152-66160
90. Air Strainer Element 1 70152-66141
91. Nut (Self Lock) Air Strainer 1 92522-230600
92. Air Strainer Body 1 70152-66011
93. Intercooler Safety Valve (Not Shown) 1 VV431
*Includes Nut(S) and Sleeve(S) #Not Supplied On Basics
