System Menu
Main Menu System
Function DVI Selection DVI-D
Scopes & Audio Meters DVI Pixel Format Full RGB
Video Component Input COMPONENT
Audio Component Pixel Format YPbPr
Marker 3G Level B Stream 1
System SDI Hue Adjustment Off
Alarm Luminance 35
OSD Luminance Interval On
GPI LED Light On
Display Alignment UDisk Mode On
System Status DHCP On
Support Load Prole Default
Save Prole Prole 1
3G Level B 3D Monitoring Modes
In addition to this Line by Line mode all FSI monitors with 3Gbps SDI inputs will have the following diagnostic modes for
monitoring 3D signals without glasses:
3D Checkerboard: Checkerboard display of both signals with alternating blocks shown from Link A and Link B of the
multiplexed 3Gbps SDI signal. The checkerboard size is adjustable using the Checkerboard Size menu option.
3D Disparity: This shows an overlay of Link and Link B with differences between the links highlighted.
Stream 1, Stream 2, PAP, Horizontal Split, and Vertical Split: As with all Level B 3Gbps SDI signals these 3G Level B
viewing modes can be useful for analyzing and comparing Left and Right Eye streams.
