System Menu

Main Menu System

Function DVI Selection DVI-D

Scopes & Audio Meters DVI Pixel Format Full RGB

Video Component Input COMPONENT

Audio Component Pixel Format YPbPr

Marker 3G Level B Stream 1

System SDI Hue Adjustment Off

Alarm Back Light 35

OSD Back Light Interval On

GPI LED Light On

Display Alignment Language English

System Status Part Display Off

Support Load Prole Default

Save Prole Prole 1

SDI Hue Adjustment

This option allows you to activate the HUE (PHASE) adjustment while monitoring in SDI. In analog monitoring modes (i.e.

Composite Video) the HUE (PHASE) adjustment will always be active. Technically speaking Serial Digital being both a

Digital and YCbCr or RGB video format should not require a HUE (PHASE) adjustment, but should you wish to have such

an adjustment in SDI you should set this option to On.

Luminance

This setting adjust peak white luminance on the display and is the correct way to increase or decrease overall display

luminance (not the brightness setting).

Luminance Interval

The luminance interval is a power saving feature; It allows you to specify the amount of time without an active signal being

shown on the monitor that should be allowed to expire before the monitor’s backlight (if applicable) is turned off to reduce

the power consumption of the unit. When placed in the On position the monitor will not enter the power saving mode and

will keep the backlight on so long as the monitor is left on.

LED Light

Allows you to turn off the LED lights on the Monitor’s Keypad.

UDisk Mode

The default setting ON allows your monitor to permanently remain in update mode. When on you can simply plug your

monitor into any compatible computer with the provided USB to RJ-45 update cable and it will be recongized as a USB

mass storage device for transfer of new rmware and/or 3D LUTs. This should only be turned OFF when using GPI control.

Part Display

Toggles whether just the center part (On) or entire source (Off) is shown in Sub Window Mode.

Load Prole

Recall Saved Prole Settings. Highlight desired prole & press ENTER to activate the saved prole selection.

Save Prole

Saves all current monitor settings under a recallable prole by highlighting Prole number & pressing ENTER.
