FSI BM Series User Manual

© 2014 Flanders Scientic, Inc.
7
Return to Table of Contents
Menu Navigation / System Status
Main Menu
Pressing the MENU button on the monitor’s keypad will call up the On Screen Menu, as shown below:
Main Menu Function
Function F1 Scopes & Audio Meters 1
Scopes & Audio Meters F2 Scopes & Audio Meters 2
Video F3 Scopes & Audio Meters 3
Audio F4 Marker 1
Marker F5 Measurement (10Bit)
System Function Display On
Alarm
OSD
GPI
Color Management
System Status
Support
Navigating the Main Menu
To navigate the Main Menu simply use the UP and DOWN keys to highlight a category and press the ENTER button to
select the highlighted sub menu. Navigate the sub menu in the same way by using the UP and DOWN keys to highlight a
particular function and press ENTER to toggle between that function’s settings. To exit the menu or back out of a sub menu
simply press the MENU button.
System Status Category
The System Status category does not contain any congurable settings, but does provide important information regarding
your monitor’s serial number, rmware version, & current conguration.
Main Menu System Status
Function Input DVI-D
Scopes & Audio Meters Input Mode 1080p 60hz
Video Overscan Off
Audio Pixel Mapping Off
Marker Volume 16
System Contrast 0
Alarm Brightness 0
OSD Chroma 0
GPI Hue 0
Color Management Model BM210
System Status Version 1.0.00-1969
Support S/N M210A0000
Note that pressing an input button will temporarily call up a secondary system status summary window that will indicate
incoming signal resolution and frame rate, active color space selected on Color Management menu, gamma response
selected on Video Menu, & color matching function selected on Color Management Menu*.
*Color Matching Function toggle only works on OLED units, all other units currently use CIE 1931 CMF only.
