Monitor Specications
LM Series
LM-0750W
Panel Specications
Screen Size 7”
Resolution 800x480
Aspect Ratio 15:9
Bit Depth (Colors) 8 (16.7M)
3D Polarizing Filter No
Processing 12 Bit
Contrast Ratio 500:1
Backlight White LED
Max Luminance 300nit
Viewing Angle 160°
Inputs
1x DVI-I DVI-I (Analog/Digital)
2x BNC 3gbps/HD/SD-SDI
1x BNC Composite
3x BNC Component
(YPbPr/RGB)
Outputs
2x BNC N/A
1x BNC 3Gbps/HD/SD-SDI
3x BNC N/A
Audio
Audio Disembedding Yes
Audio Level Meters Yes
Internal Speakers 2
Audio In N/A
Audio Out 1 Mini-Phono
Supported SDI Formats
ITU-R BT.656 (PAL) 576i (50)
SMPTE-125M 480i (59.94)
SMPTE-274M 1080i (60/59.94/50) 1080p
(30/29.97/25/24/24Ps-
F/23.98/23.98PsF)
SMPTE-296M 720p
(60/59.94/50/30/29/25/24/23.98)
2K 2048x1080 (23.98PsF/24Ps-
F/23.98p/24p)
SMPTE-372M N/A
SMPTE-425M Standard (Level A & B)
Supported DVI Formats
DVI-A & DVI-D VGA (640x480), NTSC (720x480),
SVGA (800x600), XGA
(1024x768), SXGA (1280x1024)
DVI Digital Only 1280x720, 1440x900, 1920x1080
BM Series
BM090 BM210 BM230
Panel Specications
Screen Size 9” 21.5” 23”
Resolution 1920x1080 1920x1080 1920x1080
Aspect Ratio 16:9 16:9 16:9
Bit Depth (Colors) 8 (16.7M) 8 (16.7M) 8 (16.7M)
3D Polarizing Filter No No No
Processing 12 Bit 12 Bit 12 Bit
Contrast Ratio 750:1 1000:1 1000:1
Backlight White LED White LED White LED
Max Luminance 250nit 250nit 250nit
Viewing Angle 178° 178° 178°
Inputs
1x DVI-I DVI-I (Analog/Digital) DVI-I (Analog/Digital) DVI-I (Analog/Digital)
2x BNC 3Gbps/Dual Link/HD/SD-SDI 3Gbps/Dual Link/HD/SD-SDI 3Gbps/Dual Link/HD/SD-SDI
1x BNC N/A Composite Composite
3x BNC N/A Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Outputs
2x BNC 3Gbps/Dual Link/HD/SD-SDI 3Gbps/Dual Link/HD/SD-SDI 3Gbps/Dual Link/HD/SD-SDI
1x BNC N/A Composite Composite
3x BNC N/A Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Audio
Audio Disembedding Yes Yes Yes
Audio Level Meters Yes Yes Yes
Internal Speakers 2 2 2
Audio In N/A 1 Mini-Phono 1 Mini-Phono
Audio Out 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono
Supported SDI Formats
ITU-R BT.656 (PAL) 576i (50)
SMPTE-125M 480i (59.94)
SMPTE-274M 1080i (60/59.94/50) 1080p (30/29.97/25/24/24PsF/23.98/23.98PsF)
SMPTE-296M 720p (60/59.94/50/30/29/25/24/23.98)
2K 2048x1080 (23.98PsF/24PsF/23.98p/24p)
SMPTE-372M 1080i (29.97/25/24/23.98) 1080p (30/29.97/25/24/23.98) 720p (60/59.94/50) 4:4:4 YCbCr, RGB
SMPTE-425M Standard (Level A & B)
Supported DVI Formats
DVI-A & DVI-D VGA (640x480), NTSC (720x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024)
DVI Digital Only 1280x720, 1440x900, 1920x1080
