Monitor Specications
CM Series
CM171 CM172 CM240 CM250 CM420TD CM500TD
Panel Specications
Screen Size 17.3” 16.5” 24” 24.5” 42” 50”
Resolution 1920x1080 1920x1080 1920x1200 1920x1080 1920x1080 1920x1080
Aspect Ratio 16:9 16:9 16:10 16:9 16:9 16:9
Bit Depth (Colors) True 10 bit (1.073B) 10 bit OLED (1.073B) 10 bit FRC (1.073B) 10 big OLED (1.073B) True 10 bit (1.073B) True 10 bit (1.073B)
3D Polarizing Filter No No No No Yes Yes
Processing 12 Bit 12 Bit 12 Bit 12 Bit 12 Bit 12 Bit
Contrast Ratio 1000:1 ≥ 5000:1 1100:1 ≥ 5000:1 1600:1 1600:1
Backlight RGB LED N/A OLED CCFL N/A OLED White LED White LED
Max Luminance 250nit TBA 350nit TBA 250nit 250nit
Viewing Angle 178° 179° 178° 179° 178° 178°
Inputs
1x DVI-I DVI-I (Analog/Digital) DVI-I (Analog/Digital) DVI-I (Analog/Digital) DVI-I (Analog/Digital) DVI-I (Analog/Digital) DVI-I (Analog/Digital)
2x BNC 3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
1x BNC Composite Composite Composite Composite Composite Composite
3x BNC Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Outputs
2x BNC 3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
3Gbps/Dual Link/HD/
SD-SDI
1x BNC Composite Composite Composite Composite Composite Composite
3x BNC Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Component
(YPbPr/RGB)
Audio
Audio Disembedding Yes Yes Ye s Yes Ye s Yes
Audio Level Meters Yes Yes Ye s Yes Yes Ye s
Internal Speakers 2 2 2 2 2 2
Audio In 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono
Audio Out 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono 1 Mini-Phono
Supported SDI Formats
ITU-R BT.656 (PAL) 576i (50)
SMPTE-125M 480i (59.94)
SMPTE-274M 1080i (60/59.94/50) 1080p (30/29.97/25/24/24PsF/23.98/23.98PsF)
SMPTE-296M 720p (60/59.94/50/30/29/25/24/23.98)
2K 2048x1080 (23.98PsF/24PsF/23.98p/24p)
SMPTE-372M 1080i (29.97/25/24/23.98) 1080p (30/29.97/25/24/23.98) 720p (60/59.94/50) 4:4:4 YCbCr, RGB
SMPTE-425M Standard (Level A & B)
Supported DVI Formats
DVI-A & DVI-D VGA (640x480), NTSC (720x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024)
DVI Digital Only 1280x720, 1440x900, 1920x1080, 1920x1200
