MISC MENU
SYSTEM SAVE
CONFIG SERIAL >>
TECH SUPPORT >>
BACKLIGHT >>
A/V MODE INTEGR
REMOTE PROTOCOL >>
FACTORY RESET >>
System Save
Allows the user to save the input file settings to non-volatile memory.
Config Serial
Allows the user to change ECHO from ON/OFF. BAUD RATE can be adjusted from 1200, 9600, 19.2K and 38.4K.
DATA BIT has the option of 7 or 8. STOP BIT can be changed between 0 and 1. PARITY supports NONE, EVEN or
ODD. RESET will default the settings to Baud = 38.4, Parity = None, Data Bits = 8 and Parity = None. These settings
are used for both RS232 and RS485 communications.
CONFIG SERIAL
ECHO ON
BAUD RATE 38.4K
DATA BIT 8
STOP BIT 1
PARITY NONE
RESET RS-232
Tech Support Menu
Displays the latest version of software and customer service numbers to contact if a problem is encountered.
TECH SUPPORT MENU
SOFT VER 1.06 0 A
PHONE 800.332.FSR1
Remote Protocol Menu
Provides the user with a means to set the serial communication protocol between RS232 and RS485. If RS485 is
selected, the unit's ID can be set to any number from 1 to 32. The front panel is locked when the RS485 protocol is
selected.
REMOTE PROTOCOL
SERIAL MODE RS232
Backlight Menu
Allows the user to choose whether the display buttons are lighted or not.
