FTI LB-10 - Figure 1.3-2 Little Brute Specifications

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: (206)246-2010 Fax: (206)244-9886
57429 – Rev L 3
Model
Number
Maximum
Material
Stackup
(inch)
L
(inch)
F
(inch)
Weight
(lb.)
Stroke
(inch)
LB-10
1.0
(25.4 mm)
9.2
(233.7 mm)
4.0
(101.6 mm)
10.75
(47.8N)
2.0
(50.8 mm)
LB-15
1.5
(38.1 mm)
10.2
(259.1 mm)
4.5
(114.3 mm)
11.00
(48.9N)
2.6
(66.0 mm)
LB-20
2.0
(50.8 mm)
11.2
(284.5 mm)
5.0
(127.0 mm)
11.25
(50.0N)
3.1
(78.7 mm)
LB-20-FVC
2.0
(50.8 mm)
11.2
(284.5 mm)
5.0
(127.0 mm)
11.25
(50.0N)
3.1
(78.7 mm)
LB-20-FVS
2.0
(50.8 mm)
11.2
(284.5 mm)
5.0
(127.0 mm)
11.25
(50.0N)
3.1
(78.7 mm)
LB-25
2.5
(63.5 mm)
12.2
(309.9 mm)
5.5
(139.7 mm)
11.50
(51.2N)
3.6
(91.4 mm)
LB-30
3.0
(76.2 mm)
13.2
(335.3 mm)
6.0
(152.4 mm)
11.75
(52.3N)
4.1
(104.1 mm)
LB-35
3.5
(88.9 mm)
14.2
(360.7 mm)
6.5
(165.1 mm)
12.00
(53.4N)
4.6
(116.8 mm)
Figure 1.3-2
Little Brute Specifications
L (ref)
F (ref)
1.5
