Specifications
Analog Inputs
Quantity 8
Connector XLR-F
Input Levels -60 to +10 dBu (0.775mv to 2.5VRMS)
Input Impedance 1k ohms
Phantom Power Software enabled by channel, +12V
THD+N 0.025% condition: -30dBu input (25mV RMS)
CMRR 80dB
Frequency Response 20 to 20kHz ± 3dB
DR Compression Available
Noise Gating Available
Trim Control Software controllable, >90dB range, 0.5dB steps
Mixer
Recording Device Source Selection Any combination of the 8 inputs for each of 4
Recording outputs to USB
Monitor Source Selection (1 to 4) Any combination of the 8 inputs for each of the
Monitor outputs 1 to 4
Monitor Source Selection (All) All 8 inputs mixed down to 1 output
A/D and D/A Conversion
Conversion 16 bits
Sample Rates 8,11.025,12,16,22.05,24,32,44.1,48 KHz
Physical Recording Devices 4
