Appendix A
12345678
POWER
DMX8 USB Mixer
Input Levels
ForTheRecord
FTR Pty Ltd
Front Panel
Rear Panel
87654321
MONITOR
All
USB
Ch 1
Ch 2
Ch 3
Ch 4
ANTEX ELECTRONICS
UN2468-3
INPUTS
115/230V
50-60Hz
25 WATTS
Diagram 1 – DMX8 Front and Rear Panels
Page 26
