Paper Jam in the Document Feeder (DADF)
5: Lower green lever on
the left corner.
37
37
Paper Jam in Paper Tray (Tray 1, 2,3, 4 and Bypass Tray 5)
1: Pull out Paper Tray and
remove jammed paper.
Gently push the tray in.
3: Check the paper &
reload paper into the
Tray.
Maintenance : Clearing Paper Jams
Maintenance : Clearing Paper Jams
Maintenance : Clearing Paper Jams
4
5
6
1: Lift up cover & remove
jammed original..
1
2: Carefully remove any
jammed original.
4: If paper jammed
underneath, lift up DADF
Tray.
6: Remove any jammed
paper. Close cover to
original position.
2
3: Remove any jammed
original underneath cover.
Close all the covers.
NOTE: Follow instructions displayed on the Touch Screen to remove the jammed paper.
3
1
2
3
2: Inspect paper feed Tray 5
(Bypass). Remove
jammed paper if any.
To Next Page
