16 Appendix
654
Appendix
16
Folder Unit CD1 (optional)
Booklet Finishing
Maximum number of sheets : 20 sheets
*1
,
5 sheets (center folding)
Paper size : Maximum: 13 x 18",
Minimum: A4, 8.5 x 11"
Paper type : 64 - 220 gsm
*2
,
64 - 220 gsm (center folding),
64 - 220 gsm (single folding)
*1 : 14 sheets when attaching a cover. The maximum number of sheets for center folding can
be changed by customer engineers.
*2 : Up to 220 gsm paper can be used for covers. When 91 to 220 gsm paper is used for a cover,
paper that can be used for body contents becomes 64 to 80 gsm.
Important • When using 80 gsm paper.
Folding
(Z-Fold, Three Fold)
<Z-Fold>
Paper size : A3, B4, 11 x 17"
Paper weight : 64 - 90 gsm
<Three-Fold>
Paper size : A4, 8.5 x 11"
Paper weight : 64 - 90 gsm
Inserter Paper size : Maximum: A3, 11 x 17",
Minimum: B5
Important • You cannot copy on the paper loaded in inserter.
Paper weight : 64 - 220 gsm
Capacity : 200 sheets
Important • When using 80 gsm paper.
Power Supply/Power
Consumption
220 - 240V AC ±10%, 1A /110V ±10%, 2A for both 50/60 HZ ± 3%
Maximum Power Consumption: 200W
Dimensions/Weight Width 1,250 x Depth 725 x Height 1,165 mm, 175 kg
Note • This weight includes the staple cartridge.
Space Requirement Width 2,425 x Depth 804 mm (main unit + Finisher D2-P with Booklet
Maker (when D2 Folder Unit is installed), when the Middle Size Color UI is
installed, and the bypass tray and the extension tray are fully extended)
Width 2,425 x Depth 804 mm (main unit + Finisher D2-P with Booklet
Maker (when D2 Folder Unit is installed), when the Large Size UI Kit is
installed, and the bypass tray and the extension tray are fully extended)
Paper Size Z fold: A3, 11 × 17", B4
C fold: A4, Letter
Paper Weight Z fold: 64 - 90 gsm
C fold: 64 - 90 gsm
Paper Capacity C fold: 40 sheets
Power Supply/Maximum
Power Consumption
220 - 240 VAC ±10%, 0.6 A for both 50/60 Hz
120 W or less
Dimensions/Weight Width 232 x Depth 726 x Height 991mm, 53 kg or less
Important • The Folder Unit CD1 needs a power supply besides the one for the
main unit.
• When using 80 gsm paper.
To Next Page
