3 Maintenance
84
Maintenance
3
Replacing Booklet Staples (for C3 Finisher with Booklet Maker)
When the C3 Finisher with Booklet Maker (optional) is installed and the booklet staple
cartridges need to be replaced, a message appears on the touch screen. When this message
appears, replace the booklet staple cartridges with new ones.
* : The above message is for the booklet staple cartridge [R2] on the front side. [R2] will be [R3] in the message for the booklet
staple cartridge [R3] on the back side.
Important • The use of booklet staple cartridges not recommended by Fuji Xerox may degrade quality and
performance. Use only booklet staple cartridges recommended by Fuji Xerox.
Note • If the booklet staple cartridge was not replaced properly, the message remains on the touch screen.
Follow the procedure and replace the booklet staple cartridge again.
• To order a booklet staple cartridge, contact our Customer Support Center.
1 Make sure that the machine is not operating,
and open the finisher front door.
2 Pull out the booklet unit.
3 With grasping the lever of the booklet staple
cartridge ([R2] or [R3]), push the booklet staple
cartridge downward. Then, pull out the booklet
staple cartridge upward.
Message
*
Solution
The Booklet Staple Cartridge [R2] is running out
of staples.
Please order a Booklet Staple Cartridge [R2].
Prepare new staples.
Note • Staples cannot be replaced yet.
The Booklet Staple Cartridge [R2] is out of
staples or not fully inserted.
Check the Staple Cartridge [R2].
Replace staples with new ones.
To Next Page
