Machine Components
55
Product Overview
2
îš„ A3 High Capacity Feeder (optional)
No. Component Function
1 Tray 5 (Bypass) Used for loading non-standard paper (thick-stock paper, and other special
media) that cannot be loaded in Trays 1 to 4, and 6.
2 Tray 5 (Bypass) top cover Open this cover to clear paper jams.
3 Front door of the High
Capacity Feeder
Open this door to clear paper jams. This unit conveys paper supplied from
Tray 6 or Tray 5 (Bypass) to the machine.
4 Consumable storage space Store consumables and paper here.
5 Tray 6 Load paper here.
6 Ground fault interrupter Automatically turns the machine off when a current leakage is detected.
To Next Page
