Stapler Faults
597
Problem Solving
15
Staple Jams in Booklet Staple Cartridge
(for D2-Staple-Finisher with Booklet Maker)
The following describes how to clear staple jam occurred in the booklet staple cartridge of
the D2-Staple-Finisher with Booklet Maker (optional).
1 Make sure that the machine is not operating,
and open the finisher right door.
2 While pressing the handle to the right (1), take
the booklet staple cartridge unit out of the
finisher (2).
3 Hold the tabs on both sides of the booklet
staple cartridge.
4 Rotate the booklet staple cartridge at an angle.
5 Lift the booklet staple cartridge out of the unit.
To Next Page
