38 3 Basic Operations
Interior View
No. Name Description
15 Fuser unit Fixes the toner on the paper. Do not touch this when using the
printer as it is hot.
16 Drum/toner cartridge Contains parts such as toner, OPC drum, and developer unit.
Replace the drum/toner cartridge with a new one when printing
becomes faded or poor.
17 Rib plate Transfers the printed paper to the front cover correctly. Clean it if
the print quality becomes poor.
