18 1 Installing the Printer
4. Place the drum/toner cartridge on a flat
surface and pull out the seal horizontally.
Important
• When pulling out the seal, pull it out horizontally. The
tape might break if it is pulled out at an angle.
• After the seal has been pulled out, do not shake or
bump the drum/toner cartridge.
5. Hold the drum/toner cartridge by the grip
and align the protrusions of the cartridge
with the grooves inside the printer, and then
slide it into the grooves as shown in the
diagram.
Important
• Do not touch any parts inside the printer.
• Ensure that the drum/toner cartridge is firmly set.
6. Close the top cover.
7. Close the front cover until it clicks.
To Next Page
