Connecting external devices
54 10600572101, edition 1
Connecting external audio devices
Headphones port
Via the headphone port you can connect either headphones or external loudspeakers to your
notebook.
Microphone jack
Via the microphone port you can connect an external microphone to your notebook.
Adjusting the volume
► Set the desired volume with the key combination Fn + F10 or Fn + F11 .
Or
► To adjust the volume use the Windows volume control from the Start menu - All Programs -
Accessories - Multimedia - Volume Control.
Connecting an external device to S-Video Out
You can connect an external device (e.g. a TV) to the S-Video Out socket of your notebook to view
films from DVDs, photos or presentations etc.
Using the Fn + F3 key combination you can switch back and forth between the external device
and the LCD screen.
► Switch off the notebook and the external device.
► Connect the external device to the S-Video Out socket of your notebook.
► First switch the external device on and then the notebook.
Activating external device
► Select the monitor type in the menu Start - Control Panel - Appearance and Themes - Display -
Settings - Advanced - Displays.
► Click on Apply.
