Technical data
68 10600572101, edition 1
Ports
Monitor port: 15-pin female connector
Microphone jack: connector, mono
Headphone/loudspeaker connector: connector, stereo
S Video out socket: 4-pin mini DIN female connector
USB port (Universal Serial Bus): 4x 2.0/1.1
LAN connector: Female connector, RJ-45
Modem port: Female connector, RJ-11
Kensington Lock present
Environmental conditions
Environment class 7K1 DIN IEC 721
Mechanical class 7M2 DIN IEC 721
Temperature:
Operating (7K1)
Transport (2K2)
5 °C .... 35 °C
-15 °C .... 60 °C
Dimensions
Width/depth/height: 330 mm/278 mm/35.3 mm
Weight (depending on configuration): approx. 2.7 kg
Battery
4-cell rechargeable battery (PSXX or SMPPSXX identifier)
Charge time: approx. 2 hours (when switched off)
Operating time approx. 1.5 hours (depending on application and
power management settings)
8-cell rechargeable battery (PS or SMPPS identifier)
Charging time (when not in operation): approx. 3 hours (when switched off)
Operating time approx. 2.5 hours (depending on application and
power management settings)
Power adapter 65 W
Main
● Rated voltage: 100 V to 240 V (automatic)
● Frequency: 50 Hz to 60 Hz (automatic)
Sub
● Rated voltage: 20 V
● Max. rated current: 3.25 A
