Mainboard D1520
List of features
Onboard features D1520-A
Chipset i845GE
Board size µ-ATX
VGA
Audio / 6-channel / S/PDIF / /
Buzzer / int. Speaker Support / -
LAN / with Alert-on-LAN / -
HI-SPEED USB 2.0
SmartCard Reader Support (USB / serial) - / -
Temperature monitoring -
System Monitoring -
Fujitsu Siemens Computers Keyboard Power
Button Support
-
Internal ports
DIMM Sockets (DDR 333 SDRAM, PC2700) 2
AGP Slot (2/4x, 32 bit, 66 MHz, 1.5 V) 1
PCI slot (32 bit, 33 MHz, 5 V and 3.3 V) 3
CNR Slot (Type A, AC‘97 only) 1
IDE Interface (Ultra DMA/100) 2
Floppy Interface (up to 2.88 MB) 1
S/PDIF* (digital audio) 1
CD / AUX audio input 1 / -
Frontpanel Audio (headphone, microphone) 1
Wake On LAN -
USB Ports* (2.0, ~480 Mb/s) 4
Serial Ports* (FIFO, 16550 compatible) 1
Fan Connectors PSU** / FAN1 / FAN2 / FAN3 - / 1 / 1 / -
SMBus Connector* (Case Temperature) -
Intrusion Connector* (Case Open) -
Power Connectors ATX / ATX12V / AGP PRO 1 / 1 / -
A26361-D1520-Z120-1-6319 English - 3
