A26361-D1555-Z120-1-6319 English - 7
Interfaces and connectors
The positions of the interfaces and connectors are shown on page "Cover".
The components and connectors marked are not necessarily present on the mainboard.
External ports
The positions of the external ports are shown on page "Cover".
PS/2 keyboard port, purple PS/2 mouse port, green
Serial interface, turquoise Parallel port/Printer, burgundy
LAN
LAN connector USB - Universal Serial Bus, black
Audio output (Line out), light green Microphone jack (mono), pink
Audio input (Line in), light blue
LAN connector
This mainboard has an ADMtek AN983B LAN controller. The LAN controller is equipped with a 2 KB
transmission and receiving buffer (FIFO) and supports WOL function through Magic Packetä.
The LAN RJ45 connector has two LEDs (light emitting diodes).
1
2
1 = a connection exists (e.g. to a hub).
2 = Link Mode: the LAN connection is active.
WOL mode: a Magic Packet
TM
is being
received.
Internal ports and connectors
The positions of the internal ports and connectors are shown on the Cover. Additional information on
some ports is also provided here.
Hard disk connection
An ultra ATA/66, ultra ATA/100 or ultra ATA/133 hard disk must be connected with a cable
especially designed for the ultra ATA/66, ultra ATA/100 or ultra ATA/133 mode.
Ê Connect the end of the cable marked with blue to the mainboard.
