Pin assignment of internal ports
10 - English A26361-D1555-Z120-1-6319
Lüfter 1 / Fan 1
(processor fan - only for 3 pin fans)
1
Pin Signal
1GND
2 Fix Fan voltage (+12 V, max. 1 A)
3 Fan sense
Lüfter 2 / Fan 2
(system fan - only for 3 pin fans)
1
Pin Signal
1GND
2 Fix Fan voltage (+12 V, max. 1 A)
3 Fan sense
Stromversorgung ATX12 V /
Power supply ATX12 V
13
Pin Signal Pin Signal
1 GND 2 GND
3 +12 V 4 +12 V
