Brief description of mainbo ard
Brief description o f mainboar
d
Information about boards
Be sure to observe the following for bo ards with ESD :
• You must always discharge static build up (e.g. by touch ing a grounded object)
before working w ith the board.
• The equipment and tools you use must be free o f static charge.
• Remove the power plug from the mains supply before inserting or removing
boards.
• Always hold boards by their e dges.
• Never touch connector pins or conductors on the board.
An ove rview of the features is p rovided in the data sheet.
Special features
Your mainboard is available in different configuration levels. D epending on the c on figuration,
your mainboa rd will be equipped with or provide support fo r certain features.
This manual describes the most important properties of this mainboard.
Additional information on mainboards is provided in the manual "Ba sic informat ion on mainboard"
on the "U ser Documentation" or "OEM Mainboard" CD, or on th e Internet.
Interfaces and connectors
The location of the interf
aces a nd connectors of your mainboard is specified
at the beginning of the man
ual.
The components and connect
ors marked are not necessarily present on th e mainboard.
External ports
The location of th e extern
al connections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard port, violet (optional) PS/2 mouse port, green (optional)
LAN port (RJ-45) Microphone jack (mon o), pink
Audio input (Line in), light blue USB – Universal Serial Bus, black
Audio output (Line out),
light green
VGA, blue
Serial interface, turqu
oise
A26361-D2721-Z110-1-7419, edition 3 English - 1
