Mainboard D2721 - In ternal connecto
rs and slots
External connectors rear
USB - dual channel
1
2
1 = VCC C
2 = VCC D
3 = Data negative C
4 = Data negative D
5=
6 = Data positive D
Data positive C
7 = GND
8 = GND
Optionale Komponenten / Optional components
9= Key
10 = Not connected
A26361-D2721-Z140-1-7619
Slot 1
Slot 2
Slot 3
Slot 4
PCI Express x16
Power supply
Power supply
control
Front panel
Additional
power supply
Fan 1
PCI
PCI
PCI Express x1
DVI
USB
USB
SATA
2
SATA5
SATA4
SATA
3
Parallel Port
Fan 2
Battery
Front
Audio
Floppy disc drive
TPM
SATA
0
SATA
1
LAN
LAN
SPDIF
Audio
Intru
sio
n
A26361-D2721-Z110-1-7419, Ausgabe 3
