24" LCD Monitor
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Technical data
Dimensions and weight (LCD monitor)
Visible diagonals: 61.1 cm (24”)
Screen size : 518.4 mm x 324.0 mm
Dimensions (W x H x D)
incl. monitor base : 568.0 mm x 453.5 mm x 262.9 mm
Dimensions box (W x H x D): 650 mm x 544 mm x 278 mm
Weight : unpacked/packed approx. 6.8 kg / 9.8 kg
Dot pitch : 0,270 mm
Maximal resolution : 1920 x 1200 pixels
Electrical data
Video: analogue, positiv, 0.7 Vpp, 75 Ω,
digital, DVI-D(optional)
Synchronisation : Seperate Synch. TTL, positive or negative
Horizontal frequency: 31 kHz …. 81 kHz
Refresh rate: 56 Hz …. 75 Hz
Maximum pixel rate: 162 MHz
Power supply: switches automatically
100 V – 240 V, 50 Hz – 60 Hz, 1.6 A max.
Total power consumption: < 105 W
< 1 W in the energy-saving modes
(standby mode, suspend mode and Off mode)
Environmental conditions
Environment class 3K2, IEC 721
Operating range: 5 °C …. 35° C
Humidity: 20 % …. 85 %
Condensation must be avoided.
Preset operating modes
The picture position and size have been set set to optimum values at the factory for the
operating modes listed above.
Horizontal frequency Refresh rate Display resolution
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60.0 kHz
64.0 kHz
79.9 kHz
65.3kHz
74.0kHz
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60Hz
60Hz
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
1680 x 1050
1920 x 1200
