Fujitsu 6240 - fi - Document Scanner

4.3 Cleaning the ADF
No. Item
1 Brake rollers (x 2)
2 Feed rollers (x 2)
3 Eject rollers (x 2)
4 Glasses (x 2)
5 Pick rollers (x 2)
6 Plastic rollers (x 4)
7 Ultrasonic sensors (x 2)
ATTENTION
To avoid damaging the document sensors, take care that the cloth does not get hooked into
them when cleaning the inside of the ADF.
Document sensor
