3. Specify the length for each end section; top, bottom, right, and left, to fill the end sections.
ADF FB
T: Top edge=0 to 15 mm Top edge=0 to 15 mm
D: Bottom edge=–7 to 7 mm Bottom edge=0 to 15 mm
R: Right edge=0 to 15 mm Right edge=0 to 15 mm
L: Left edge=0 to 15 mm Left edge=0 to 15 mm
(can be set in increments of 1 mm) (can be set in increments of 1 mm)
The specified areas are filled with white when the backing (background) is white, and with black when the backing is
black.
HINT
Unless otherwise specified, the background color is white. You can also change it to the
“Black background” using the scanner driver.
If you are using the TWAIN driver, do the following to change the background color to black:
Select the [Option] button, and then select [Black background] from [Automatic Size and
Skew detection] on the [Rotation] tab.
ATTENTION
Note that if the Page Edge Filler is too wide, some characters in the vicinity of the boundary
may be cut out.
