- (01-137) -
MULTI TYPE
2, 3, 4 ROOMS TYPE
MULTI TYPE
2, 3, 4 ROOMS TYPE
SLIM DUCT TYPE
CenterCenter
Front viewSide view
1.5m
2m 1m
Microphone
Measuring duct Measuring duct
Microphone
WALL MOUNTED TYPE
1m
0.8m
Microphone Microphone
