- (03 - 49) -
OUTDOOR UNIT
AO
G18-24L3
OUTDOOR UNIT
AO
G18-24L3
SAFETY DEVICES11.
Pressure switch (2) : For control device
Protection form
Model
AO
G18L3 AO
G24L3
Circuit protection
Current fuse (MAIN PCB)
5A 250V
3.15A 250V
Current fuse
(NEAR THE TERMINAL TO
POWER SUPPLY)
25A 250V
Current fuse
(NEAR THE TERMINAL TO
INDOOR UNIT)
10A 250V
Fan motor protection Thermal protector
OFF :130±20°C
ON : 100±20°C
Compressor protection Thermal protector
OFF : 110°C
ON : 80°C
High pressure protection Pressure switch (1)
OFF :4.2±0.10MPa
ON : 3.2±0.15MPa
