FUNCTION SETTINGS13.
INDOOR UNIT (setting by jumper wire)13-1.
Note: This function is Slim Duct type only.
SWITCH POSITION

Slim Duct type
z
JM1
JM2
JM3
JUMPER WIRE SETTING

Drainage function setting (JM1)
z
(
u
...Factory setting)
JM1 Drainage function
u
Connect Enable
Disconnect Disable
Auto louver grille setting (JM2)
z
When Auto louver grille kit (optional parts) is attached, set the Auto louver grille setting to "Enable".
(
u
...Factory setting)
JM2 Auto louver grille setting
u
Connect Disable
Disconnect Enable
Fan delay setting (JM3)
z
(
u
...Factory setting)
JM3 Fan delay
u
Connect Disable
Disconnect Enable
