OUTDOOR UNIT AO

G18-24L3
OUTDOOR UNIT AO

G18-24L3
Indoor unit : 9000Btu + 9000Btu + 9000Btu
z
Indoor unit : 9000Btu + 9000Btu + 12000Btu
z
Indoor unit : 9000Btu + 9000Btu + 14000Btu
z
Indoor unit* : 9000Btu + 9000Btu + 18000Btu
z
* : When "AS

G18L" is connected , 9000Btu model shall be chosen at least one "Compact wall mounted type" or more.
TC : Total Capacity (kW)
IP : Input Power (kW)
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
9+9+9
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 5.26 2.34 5.13 2.39 5.01 2.44 4.88 2.49 4.75 2.54
-10 -11 6.12 2.46 5.97 2.52 5.82 2.57 5.68 2.62 5.53 2.67
-5 -7 6.93 2.55 6.76 2.61 6.60 2.66 6.43 2.71 6.27 2.77
0 -2 7.93 2.76 7.74 2.87 7.55 2.87 7.36 2.87 7.18 2.87
5 3 8.98 2.76 8.77 2.87 8.55 2.87 8.34 2.87 8.13 2.87
7 6 9.56 2.76 9.33 2.87 9.10 2.87 8.87 2.87 8.65 2.87
10 8 9.94 2.76 9.70 2.87 9.46 2.87 9.23 2.87 8.99 2.87
15 10 10.41 2.67 10.17 2.73 9.92 2.78 9.67 2.87 9.42 2.87
20 15 9.56 2.04 9.33 2.08 9.10 2 .12 8.87 2.17 8.65 2.21
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
9+9+12
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 5.31 2.34 5.19 2.39 5.06 2.44 4.93 2.49 4.81 2.54
-10 -11 6.18 2.46 6.04 2.52 5.89 2.57 5.74 2.62 5.59 2.67
-5 -7 7.00 2.55 6.84 2.61 6.67 2.66 6.50 2.71 6.34 2.77
0 -2 8.02 2.76 7.83 2.87 7.64 2.87 7.45 2.87 7.25 2.87
5 3 9.08 2.76 8.86 2.87 8.65 2.87 8.43 2.87 8.22 2.87
7 6 9.66 2.76 9.43 2.87 9.20 2.87 8.97 2.87 8.74 2.87
10 8 10.05 2.76 9.81 2.87 9.57 2.87 9.33 2.87 9.09 2.87
15 10 10.53 2.67 10.28 2.73 10.03 2.78 9.78 2.87 9.53 2.87
20 15 9.66 2.04 9.43 2.08 9.20 2.12 8.97 2.17 8.74 2.21
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
9+9+14
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 5.31 2.20 5.19 2.25 5.06 2.30 4.93 2.34 4.81 2.39
-10 -11 6.18 2.32 6.04 2.37 5.89 2.41 5.74 2.46 5.59 2.51
-5 -7 7.00 2.40 6.84 2.45 6.67 2.50 6.50 2.55 6.34 2.60
0 -2 8.02 2.59 7.83 2.65 7.64 2.70 7.45 2.75 7.25 2.87
5 3 9.08 2.59 8.86 2.65 8.65 2.70 8.43 2.75 8.22 2.87
7 6 9.66 2.59 9.43 2.65 9.20 2.70 8.97 2.75 8.74 2.87
10 8 10.05 2.59 9.81 2.65 9.57 2.70 9.33 2.75 9.09 2.87
15 10 10.53 2.51 10.28 2.57 10.03 2.62 9.78 2.67 9.53 2.72
20 15 9.66 1.92 9.43 1.96 9.20 2.00 8.97 2.04 8.74 2.08
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
9+9+18
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 5.31 2.19 5.19 2.23 5.06 2.28 4.93 2.32 4.81 2.37
-10 -11 6.18 2.30 6.04 2.35 5.89 2.40 5.74 2.44 5.59 2.49
-5 -7 7.00 2.38 6.84 2.43 6.67 2.48 6.50 2.53 6.34 2.58
0 -2 8.02 2.57 7.83 2.63 7.64 2.68 7.45 2.73 7.25 2.79
5 3 9.08 2.57 8.86 2.63 8.65 2.68 8.43 2.73 8.22 2.79
7 6 9.66 2.57 9.43 2.63 9.20 2.68 8.97 2.73 8.74 2.79
10 8 10.05 2.57 9.81 2.63 9.57 2.68 9.33 2.73 9.09 2.79
15 10 10.53 2.50 10.28 2.55 10.03 2.60 9.78 2.65 9.53 2.70
20 15 9.66 1.90 9.43 1.94 9.20 1.98 8.97 2.02 8.74 2.06
