Type
Ceiling
Inverter, Heat pump
Model name ABUH36LUAS
Power supply intake Outdoor unit
System power supply
Voltage V 208/230
Frequency Hz 60
Available voltage range V 187—253
Indoor unit power supply (from outdoor unit) V 208/230
Capacity
Cooling
Rated
k→ 10.55
Btu/h 36,000
Min.—Max.
k→ 2.81—11.43
Btu/h 9,600—39,000
Heating
47°FDB
(Outdoor temp.)
Rated
k→ 11.14
Btu/h 38,000
Min.—Max.
k→ 2.7—12.6
Btu/h 9,200—43,000
17°FDB
(Outdoor temp.)*
1
Rated
k→ 7.09
Btu/h 24,200
Max.
k→ 10.11
Btu/h 34,500
5°FDB
(Outdoor temp.)*
2
Rated
k→ 9.09
Btu/h 31,000
Input power
Cooling
Rated
k→
3.75
Min.—Max. 0.38—4.22
Heating
47°FDB
(Outdoor temp.)
Rated 2.96
Min.—Max. 0.59—4.13
17°FDB
(Outdoor temp.)*
1
Rated 2.41
Max. 4.27
5°FDB
(Outdoor temp.)*
2
Rated 4.33
Fan
HIGH
→
94
MED 51
LO→ 34
QUIET 22
Current
Cooling
Rated A
16.5
Heating 13.0
EER2 Cooling Btu/h→ 9.60
COP2 Heating k→/k→ 3.76
SEER2 Cooling
Btu/h→
19.5
HSPF2 Heating 10.0
Power factor
Cooling
%
98.8
Heating 99.0
Moisture removal pints/h (L/h) 9.1 (4.3)
Maximum operating current*
3
Cooling
A
19.8
Heating 19.8
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
1,089 (1,850)
MED 865 (1,470)
LO→ 765 (1,300)
QUIET 618 (1,050)
Heating
HIGH 1,059 (1,800)
MED 865 (1,470)
LO→ 765 (1,300)
QUIET 618 (1,050)
Type × Qty Sirocco fan × 4
Motor output → 110
Sound pressure level*
4
Cooling
HIGH
dB (A)
44
MED 40
LO→ 37
QUIET 32
Heating
HIGH 44
MED 40
LO→ 37
QUIET 32
Heat exchanger type
Dimensions (H × → × D) in (mm) 11-9/16 × 52-9/16 × 1-9/16 (294 × 1,335 × 39.9)
Fin pitch FPI 20
Rows × Stages 3 × 14
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Steel sheet
Color
→hite
Approximate color of Munsell N9.25/
Dimensions
(H × → × D)
Net
in (mm)
9-1/4 × 66-15/16 × 27-3/4 (235 × 1,700 × 705)
Gross 13 × 70-1/4 × 32-1/2 (330 × 1,785 × 825)
→eight
Net
lb (kg)
84 (38)
Gross 106 (48)
Connection pipe
Size
Liquid
in (mm)
Ø3/8 (Ø9.52)
Gas Ø5/8 (Ø15.88)
Method Flare
Drain hose
Material PVC
Tip diameter in (mm) Ø13/16 (Ø20.7) (I.D.), Ø1-1/16 (Ø26.6) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller
Option: →ired, →ireless, Mobile app*
5
(AIRSTAGE Mobile)
1-1. Indoor unit - (01-5) - 1. Specifications
