Fujitsu ABUH18LUAS - Service Part

Item no. Part no. Part name Service part
1 9384321015 Intake grille A sub assy ♦
2 9383342011 Air filter B ♦
3 9384307002 Casing U assy ♦
4 9384110015 Sirocco fan assy ♦
5 9383443008 Rubber (Vibration proof) ♦
6 9603817008 DC fan motor ♦
7 9384311009 Casing B assy ♦
8 9383406003 Side panel L ♦
9 9384144027 Flap assy (2-fan) ♦
10 9383386008 Flap hinge ♦
11 9384375001 L and R louver assy ♦
12 9900896027 Terminal (5P) ♦
13 9711870605 Main PCB ♦
14 9384312013 Gear box sub assy (including stepping motor) ♦
15 9900960049 Thermistor (Room) ♦
16 9710661068 Power supply PCB ♦
17 9710019005 2-way remote PCB ♦
18 9306489045 Terminal (3P) ♦
19 9384320001 Side panel R sub assy ♦
20 9900892029 Thermistor (Pipe) ♦
21 9384287106 Evaporator total assy ♦
22 9384324016 Drain hose sub assy ♦
23 9384364029 Drain pan total assy (2-fan) ♦
24 9358746004 Drain cap ♦
25 9384241023 Front panel (2-fan) assy ♦
— 9710171086
→ire with connector
(CN54 on Main PCB—CN262 on Power supply PCB)
♦
— 9710206047
→ire with connector
(CN55 on Main PCB—CN263 on Power supply PCB)
♦
— 9710343056
→ire with connector
(CN300 on Main PCB—Terminal [5P])
♦
— 9710177095
→ire with connector
(CN46 on Main PCB—Terminal [5P])
♦
— 9710703041
→ire with connector
(CN205 on Power supply PCB—Terminal [3P])
♦
2-1. Model: ABUH18LUAS - (02-3) - 2. Indoor unit parts list
