Fujitsu ABUH18LUAS - Page 17

¢
Model: ABUH36LUAS
Unit: in (mm)
Top viewSide view
Rear view
Suspension bolt pitch
60-3/4 (1,543)
Indoor unit (Top view)
Indoor unit
Dimensions
(Space required for installation)
The length of the bolt
here is 1-3/16 in (30 mm).
1/4 (10)
6-1/4
(175)
11-7/16
(290)
2-15/16 (75) 2-15/16 (75)
1-15/16
(49)
3-5/16
(84)
2-3/16 (55) 4-5/16 (110)
60-3/4 (1,543)
66-15/16 (1,700)
27-3/4 (705)
8-1/8 (206)
7-1/16 (179)
4-1/2 (115)
1-5/8 (41)
4-15/16
(125)
4-1/16
(103)
13-3/4 (349)
4-11/16 (119)
5-11/16 (145)
7-1/8 (181)
3-7/8
(98)
9-1/4 (235)
3-15/16 (100)
4-15/16 (125)
3-9/16 (91)
3-1/8
(80)
5-1/2 (140)
11-7/16 (290)7 (178)
12-5/16 (313)
3-1/2 (89)
ø100-mm hole
3-1/2 (89)
4-5/16 (110)
2-1. Indoor unit - (01-11) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION
