Item no. Part no. Part name Service part
1 9384321015 Intake grille B sub assy ♦
2 9383342011 Air filter B ♦
3 9383342004 Air filter A ♦
4 9384321008 Intake grille A sub assy ♦
5 9384307002 Casing U assy ♦
6 9357921006 Bearing B assy ♦
7 9384110008 Sirocco fan assy ♦
8 9384270009 Shaft ♦
9 9378038011 Joint assy ♦
10 9383443008 Rubber (Vibration proof) ♦
11 9384110015 Sirocco fan assy ♦
12 9603816001 DC fan motor ♦
13 9384311009 Casing B assy ♦
14 9383406003 Side panel L ♦
15 9383386008 Flap hinge ♦
16 9384144010 Flap assy (3-fan) ♦
17 9384375001 L and R louver assy ♦
18 9900896027 Terminal (5P) ♦
19
9711870612 Main PCB (24 model) ♦
9711870629 Main PCB (30 model) ♦
20 9384312013 Gear box sub assy (including stepping motor) ♦
21 9384306005 Side bracket R sub assy ♦
22 9900960049 Thermistor (Room) ♦
23 9710661068 Power supply PCB ♦
24 9710019005 2-way remote PCB ♦
25 9306489045 Terminal (3P) ♦
26 9384320001 Side panel R sub assy ♦
27 9900892029 Thermistor (Pipe) ♦
28 9384287113 Evaporator total assy ♦
29 9384324016 Drain hose sub assy ♦
30 9384364012 Drain pan total assy (3-fan) ♦
31 9358746004 Drain cap ♦
32 9384241016 Front panel (3-fan) assy ♦
— 9710171086
→ire with connector
(CN54 on Main PCB—CN262 on Power supply PCB)
♦
— 9710206047
→ire with connector
(CN55 on Main PCB—CN263 on Power supply PCB)
♦
— 9710343056
→ire with connector
(CN300 on Main PCB—Terminal [5P])
♦
— 9710177095
→ire with connector
(CN46 on Main PCB—Terminal [5P])
♦
— 9710703041
→ire with connector
(CN205 on Power supply PCB—Terminal [3P])
♦
2-2. Models: ABUH24LUAS and ABUH30LUAS - (02-5) - 2. Indoor unit parts list
