Item no. Part no. Part name Service part
1 9384321008 Intake grille A sub assy ♦
2 9383342004 Air filter A ♦
3 9384307002 Casing U assy ♦
4 9357921006 Bearing B assy ♦
5 9384110008 Sirocco fan assy ♦
6 9384270009 Shaft ♦
7 9378038011 Joint assy ♦
8 9383443008 Rubber (Vibration proof) ♦
9 9603815004 DC fan motor ♦
10 9384311009 Casing B assy ♦
11 9383406003 Side panel L ♦
12 9384308009 Top panel cover assy (4-fan) ♦
13 9383386008 Flap hinge ♦
14 9384144003 Flap assy (4-fan) ♦
15 9384375001 L and R louver assy ♦
16 9900896027 Terminal (5P) ♦
17 9711870636 Main PCB ♦
18 9384312013 Gear box sub assy (including stepping motor) ♦
19 9900960049 Thermistor (Room) ♦
20 9710661075 Power supply PCB ♦
21 9710019005 2-way remote PCB ♦
22 9306489045 Terminal (3P) ♦
23 9707457056 Reactor assy ♦
24 9384320001 Side panel R sub assy ♦
25 9900892029 Thermistor (Pipe) ♦
26 9384287120 Evaporator total assy ♦
27 9384324016 Drain hose sub assy ♦
28 9384364005 Drain pan total assy (4-fan) ♦
29 9358746004 Drain cap ♦
30 9384241009 Front panel (4-fan) assy ♦
— 9710171086
→ire with connector
(CN54 on Main PCB—CN262 on Power supply PCB)
♦
— 9710206047
→ire with connector
(CN55 on Main PCB—CN263 on Power supply PCB)
♦
— 9710343056
→ire with connector
(CN300 on Main PCB—Terminal [5P])
♦
— 9710177095
→ire with connector
(CN46 on Main PCB—Terminal [5P])
♦
— 9710703041
→ire with connector
(CN205 on Power supply PCB—Terminal [3P])
♦
2-3. Model: ABUH36LUAS - (02-7) - 2. Indoor unit parts list
