Fujitsu ADUH09LUAS1 User Manual

¢ Compact cassette type
 Unit: kBtu/h, °F
• TC: Total Capacity (kBtu/h), SHC: Sensible Heat Capacity (kBtu/h).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ACUH07LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
23.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
32.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
41.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
50.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
59.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
67.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
77.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
87.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
95.0 5.88 3.97 6.65 4.52 7.01 5.21 7.50 5.85 8.02 6.40 8.27 7.33
104.0 5.56 3.55 6.29 4.05 6.63 4.66 7.10 5.24 7.59 5.73 7.82 6.56
115.0 5.25 3.16 5.93 3.60 6.25 4.15 6.69 4.66 7.15 5.10 7.38 5.84
MODEL: ACUH09LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
23.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
32.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
41.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
50.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
59.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
67.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
77.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
87.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
95.0 7.53 5.01 8.51 5.71 8.97 6.58 9.60 7.39 10.26 8.08 10.58 9.26
104.0 7.12 4.49 8.05 5.12 8.48 5.89 9.08 6.62 9.71 7.24 10.01 8.29
115.0 6.72 3.99 7.59 4.55 8.00 5.24 8.57 5.89 9.16 6.44 9.44 7.38
MODEL: ACUH12LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
23.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
32.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
41.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
50.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
59.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
67.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
77.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
87.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
95.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
104.0 9.50 5.91 10.73 6.73 11.31 7.75 12.11 8.71 12.95 9.53 13.35 10.91
115.0 8.96 5.25 10.12 5.99 10.67 6.90 11.42 7.75 12.21 8.47 12.59 9.71
MODEL: ACUH18LUAS1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
23.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
32.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
41.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
50.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
59.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
67.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
77.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
87.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
95.0 15.05 9.11 17.01 10.39 17.93 11.96 19.20 13.44 20.52 14.70 21.16 16.84
104.0 14.24 8.16 16.10 9.30 16.97 10.71 18.17 12.03 19.42 13.16 20.02 15.08
115.0 13.43 7.26 15.18 8.27 16.00 9.53 17.13 10.70 18.32 11.71 18.88 13.41
- 260 -
6-2. Cooling capacity 6. Capacity table
