Remove the 1 mounting screw.
Remove the INVERTER BOX COVER upward.
Remove the connector and cords.
10-28
Hook (2 places)
INVERTER BOX COVER
E
F
VIEW - E
W6 (Black)
W7 (White)
W200 (Red)
W2 (White)
W1 (Black)
Twist W6 and W7
2 times or more.
