VCC
OUT
GND
2
1
3
A
A
A
A
1
2
3
4
5
6
7
8
5V
13V
5V
13V
+
I C201
GP1UM271R
SW201
KSHC611BT
C203
0.1
<F>
R202
47
<1/4W>
R201
22
<1/4W>
D204
UDZS6.2B
D206
UDZS6.2B
D205
UDZS6.2B
D201
SLR-343ECT
<GREEN>
D203
SLR-343ECT
<GREEN>
D202
SL I-343DCT
<ORANGE>
CN201
8 - JB / PL I
L=250 #26 / 1061
C204
47/
10V
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LUCA
ASYG09LUCA
ASYG12LUCA
INDICATOR PCB ASSEMBLY
K10CX-1000HSE-D0
2011.03.03 30
